Hafnium Carbide Powder / HfC Powder (HfC, 99.9%, 800nm, Cubic)

Hafnium Carbide Powder
Product No NRE-11109
CAS No. 12069-85-1
Formula HfC
Molecular Weight  190.5g/mol
APS 800nm(can be customized)
Purity 99.9%
Density 12.7g/cm3
Color Gray
Melting Point 3890 °C
Boiling Point 4125 °C

Hafnium Carbide Powder

Hafnium carbide is often carbon-deficient and, therefore, its composition often expressed as HfCx (x = 0.5 to 1.0). It has a cubic crystalline structure (rock salt) at any value of x.
The hafnium carbide powder is obtained by reducing the hafnium oxide (IV) with coal 1800-2000 ° C requires a long processing time to remove all the oxygen. Alternatively, high purity HfC coatings can be obtained by vapor phase chemical deposition of a mixture of methane gas, hydrogen, and hafnium (IV) vaporized chloride. Because of the technical complexity and the high cost of the synthesis, HfC has a very limited use despite its favorable properties as high hardness and melting point properties.
The magnetic properties of paramagnetic HfCx change x ≤ 0.8 to diamagnetic in large x. an inverse behavior (day-paramagnetic passage to increase x) for Tacx, despite having the same observed HfCx crystalline structure. and photovoltaics.
